In the desorption system, add anions which are easily adsorbed by activated carbon,produce Au（CN） 2- to get carbon gold,by desorp the carbon gold,it will produce the liquid gold,through the ionization,the solid gold would appeared.

◎High temperature, high pressure, non cyanide, desorption automatic control, high efficiency,low energy consumption and fast;

b.Fast: desorption electrolysis temperature can be as high as 150 DEG C (Higher than the normal model 30-50℃),the system working pressure is up to 0.5MPa (higher than other models 0.2-0.5MPa) ,so desorption electrolysis time is very fast, generally 12h, shorten nearly 3 times than normal model

c. Low consumption: desorption electrolysis temperature is the same,no need to change the heat.Because of the fast working,the total power consumption is 1/2-1/4 than the normal system.

◎Non cyanide: in aqueous solution,no sodium cyanide required, low cost, no pollution;

◎High gold mud grade, no reverse electrolysis required, easy extraction

◎The liquid level control system, the temperature control system and the automatic control system are especially provided.

◎Safety: with three security protection measures, the intelligent system , automatic limiting pressure release mechanism, safety valve.

Standard process capability (kg / d)	Heavy load processing capability (kg / d)	Recommended model (kg / batch)
300	750	FL-200
450	1000	FL-300
650	1700	FL-450
750	1800	FL-500
900	2200	FL-600
1130	2700	FL-750
1500	3600	FL-1000
1800	4500	FL-1200
2250	5500	FL-1500
2700	6500	FL-1800
3000	7500	FL-2000
3750	9000	FL-2500
4500	11000	FL-3000
5200	13000	FL-3500
6000	15000	FL-4000
7500	18000	FL-5000

Model	Applicable scope		System equipment detail	System instrument	Operating parameters
Model	Mine scale (t / d)	Raw ore grade (g / t)
GJD-200	<150	2~8	S1 desorption column
GJD-300	150~300		S2 filter
GJD-450			S3 electrolytic cell S4 circulating pump	B1 resistance transmission diaphragm pressure gauge
GJD-500	300~500			B1 pressure indicator	Deabsorbing: ≥13.5
GJD-600				B2 diaphragm pressure gauge B3 vortex flowmeter B3 flow totalize
GJD-750			S5 electric heater		Use batch: Unlimited
GJD-1000	500~1000		S6 carbon emitter		Electrolytic start : 100 ~ 110 ℃
GJD-1200			S7 air compressor S8 desorption tank		Electrolysis end : 150 ℃ Electrolytic current: 350 ~ 1250a
GJD-1500				B4 thermal thermometer
GJD-1800				B5 temperature sensor
GJD-2000	1000~2000	2~20	S9 clear water pump	B5 temperature indicator B6 diaphragm pressure gauge	Electrolysis voltage: 2 ~ 4v
GJD-2500			S10 storage tank		150 DEG pressure: desorption column
GJD-3000			S11 magnetic pump		Upper part: 0.50 ~ 0.57mpa
GJD-3500	2000~3000		S12 storage tank S15 control cabinet	B7 level gauge	Electrolytic tank: 0.45 ~ 0.52mpa
GJD-4000				B9 temperature sensor
GJD-5000				B9 temperature indicator"
特殊型	>3000		S16 silicon rectifier cabinet S17 pickling stirred tank
